OpenVPN Config

Anyway, a typical OpenVPN Server configuration looks like the following.

dev tun-udp-1194 server 10.10.10.0 255.255.255.0 proto udp port 1194 ca /etc/openvpn/pki/ca.crt cert /etc/openvpn/pki/issued/[email protected] key /etc/openvpn/pki/private/[email protected] dh /etc/openvpn/pki/dh.pem crl-verify /etc/openvpn/pki/crl.pem remote-cert-tls client keepalive 10 120 tls-auth /etc/openvpn/pki/ta.key 0 cipher AES-256-CBC tls-cipher TLS-DHE-DSS-WITH-AES-256-CBC-SHA256 auth SHA256 tls-version-min 1.2 comp-lzo persist-key persist-tun verb 0

OpenVPN Management over Telnet

In order to access the telnet management console, the following line has to be added in /etc/openvpn/server.conf. Also the openvpn.service must be reloaded for the change to take effect.

management 127.0.0.1 7000

Alright. Next thing is, try connecting to port 7000 via telnet command. If it was a success, then we can use a small Python3 script to talk with the OpenVPN server.

A Bit of Knowledge about Common Name

Before we run any script, we need to find out the CN or Common Name used in the RSA Root Certificate. For example, if you generate the CA file with CN=mdminhazulhaque.io, both EasyRSA and OpenVPN will append this CN after the client's name. A sample server and client names could be as follows.

Server: server@mdminhazulhaque.io Client Mark: mark@mdminhazulhaque.io Client Bob: bob@mdminhazulhaque.io Client Alice: alice@mdminhazulhaque.io

Which means, the client names must be unique because OpenVPN uses the client name to map DHCP IP Addresses for remote users.

Run the Script!

Well, now we know the common name. It could be mdminhazulhaque.io, or example.com or server or anything. We need to amend the RE_COMMON_NAME regex and put the correct value there. Once done, upload the script to the OpenVPN server and run it using python3.

#!/usr/bin/env python3 import re import telnetlib import time # TODO change here RE_COMMON_NAME = "^*@mdminhazulhaque.io.*$" HOST = "127.0.0.1" PORT = "7000" INTERVAL = 5 PRE_USERS = {} def alert(user, ip, state): print(F"*{user}* {state} from {ip}") # TODO You can call Slack or API Gateway here while True: telnet = telnetlib.Telnet(HOST,PORT, 5) telnet.write("status\n") output = telnet.read_until("END\n", 1) telnet.close() CURR_USERS = {} for line in output.split("\n"): if re.search(RE_COMMON_NAME, line): user, realaddress, _, _, _ = line.split(",") ip = realaddress.split(":")[0] CURR_USERS[user] = ip connected = set(CURR_USERS.keys()) - set(PRE_USERS.keys()) disconnected = set(PRE_USERS.keys()) - set(CURR_USERS.keys()) for user in list(connected): alert(user, CURR_USERS[user], "connected") for user in list(disconnected): alert(user, PRE_USERS[user], "disconnected") PRE_USERS = CURR_USERS time.sleep(INTERVAL)

The Result

If you keep running the script in background (screen or systemd whichever you prefer), you will see activity alerts like the following.

[email protected] connected from 190.106.117.114 [email protected] connected from 186.110.104.190 [email protected] connected from 144.143.163.176 ... [email protected] disconnected from 144.143.163.176 [email protected] disconnected from 190.106.117.114 [email protected] disconnected from 186.110.104.190
