Connect to WiFi using nmcli

Connect to WiFi using nmcli

These days SoC with WiFi chip are very cheap and there exists lots of headless Linux OS for these machines. For example, Orange Pi Zero costs less than 10 US dollars.

Connecting to WiFi has been a real pain becase you need a password to connect with most SSID. And WLAN cards do not work like ethernet cards do. So modifying only /etc/network/interfaces is not enough.

Most Debian systems (may be others too) use wpa_supplicant for WLAN authentication. You need to generate wpa_passphrase for each network and configure them with /etc/network/interfaces which is really confusing. For this purpose, nmcli tool comes handy.

Simple do search of all available SSIDs by running the following command.

nmcli device wifi list

And here is the response.

*  SSID            MODE   CHAN  RATE       SIGNAL  BARS  SECURITY
   MT7620_AP       Infra  1     54 Mbit/s  100     ▂▄▆█
   MYHOME          Infra  2     54 Mbit/s  100     ▂▄▆█  WPA2
   Minhaz+         Infra  11    54 Mbit/s  95      ▂▄▆█  WPA2
   xiaomi-repeater Infra  1     54 Mbit/s  87      ▂▄▆█
   ESP8266         Infra  2     54 Mbit/s  55      ▂▄__  WPA1 WPA2
   LINK3           Infra  11    54 Mbit/s  12      ▂___  WPA1 WPA2
   AAMRA-WIFI      Infra  11    54 Mbit/s  12      ▂___  WPA1 WPA2

To connect to your desired network, simple use the following command.

$ nmcli device wifi connect MYHOME password 'p@55w0rd'
Device 'wlan0' successfully activated with 'd54d566c-fa31-4a21-ae4b-a1279d10f3e3'.

nmcli is very handy if you need to switch to different SSIDs frequently. Here is a nice guide on nmcli. Read it for more.
