Fluentd is a pretty good log collection and streaming solution for several platforms. You can easily stream your nginx logs to BigQuery via Fluentd.
There is a nicely written article on Analyzing logs in real time using Fluentd and BigQuery by Google. This guide has everything explained properly to get started with Fluentd-nginx-BigQuery.
I followed the whole process but ended up receiving the following error at /var/log/td-agent/td-agent.log
.
2019-05-07 16:13:15 +0000 [error]: #0 tables.get API project_id="farm-rock-85697" dataset="fluentd" table="nginx_access" code=403 message="accessDenied: Access Denied: Table farm-rock-85697:fluentd.nginx_access: The user 87674165174597-compute@developer.gserviceaccount.com does not have bigquery.tables.get permission for table farm-rock-85697:fluentd.nginx_access."
2019-05-07 16:13:15 +0000 [warn]: #0 emit transaction failed: error_class=RuntimeError error="failed to fetch schema from bigquery" location="/opt/td-agent/embedded/lib/ruby/gems/2.4.0/gems/fluent-plugin-bigquery-2.1.0/lib/fluent/plugin/out_bigquery_base.rb:190:in `fetch_schema'" tag="nginx.access"
What I guessed was that Fluentd could not access BigQuery table on GCP. Obviously it could not anyway because I had not authenticated gcloud
in the VM. I tried authenticating gcloud
tool from td-agent
user but failed as td-agent
has no valid shell. Also I tried the same for root
, but did not help.
Finally after one day of searching over the internet, I got some clue about putting JSON files in somewhere so the fluent-plugin-bigquery
can read it.
Go to Google Cloud Platform > APIs & Services. Then click on Credentials
and hit on the Create Credentials
button. Choose Service Account Key
from the combo box. This will open a new page where you have to fill the credential name, roles etc.
Now setup a name for this service, set correct access in Roles (i.e. BigQuery Insert) and select JSON
as type. Click Create
.
After creating the credentials, you will be able to download the file. Now open up /etc/td-agent/td-agent.conf
in your VM and change the following lines.
auth_method json_key
json_key /etc/td-agent/gcloud.json
Not to mention that you must copy the newly downloaded JSON file to your VM as gcloud.json
. The whole nginx.access
block should look something similar to this.
<match nginx.access>
@type bigquery_insert
<buffer>
flush_interval 0.1
total_limit_size 10g
flush_thread_count 16
</buffer>
auth_method json_key
json_key /etc/td-agent/gcloud.json
project "farm-rock-85697:api-project-1587663"
dataset nginx
tables www_imoney_my
</match>
Now restart td-agent
using systemctl
and check /var/log/td-agent/td-agent.log
. You can see records are successfully being inserted into BigQuery if all the credentials, roles, project, dataset and table configuration is correct.
